State-of-the-art aluminum frameset material features best-in-class strength-to-weight ratios and unique welding technologies for a high-performance ride quality.
Descripción
HIGHLIGHTS
1
ALUXX SL-GRADE ALUMINUM FRAME
2
OVERDRIVE
Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/2” lower and 1 1/8” upper) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
3
130MM FORK
130mm of travel up front allows you to easily navigate trail obstacles and singletrack terrain.
4
TUBELESS
Tubeless ready, so you can run lower tire pressure for added traction and control.
5
BOOST HUB SPACING
Boost 15x110 [F], 12X148 [R] hub spacing improves stiffness, trail handling and tire clearance.
6
INCREASED TIRE CLEARANCE
Run up to 2.6-inch tires on 27.5-inch wheel models and 2.5-inch tires on 29-inch wheel models for increased stability.
7
MOUNTS
The frame features mounts for two water bottle cages and additional mounts on the underside of the top tube to add a small gear bag for stowing tools.
8
INTERNAL CABLE ROUTING
Keeps your cables tidy and protected from the elements.
TECHS & FEATURES
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
-
- XS (27.5")
-
4’11”
5’4”
-
- S (27.5")
-
5’2” 5’7”
-
- S (29")
-
5’2” 5’7”
-
- M (29")
-
5’5” 5’9”
-
- L (29")
-
5’7” 5’11”
| XS (27.5") | S (27.5") | S (29") | M (29") | L (29") | ||
|---|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH (inch) | 14.2 | 15 | 15 | 16.1 | 16.9 |
| B | SEAT TUBE ANGLE | 76.0° | 76.0° | 76.5° | 76.5° | 76.5° |
| C | TOP TUBE LENGTH (inch) | 21.4 | 22.2 | 21.8 | 22.6 | 23.5 |
| D | HEAD TUBE LENGTH (inch) | 3.7 | 4.1 | 3.5 | 3.9 | 4.3 |
| E | HEAD TUBE ANGLE | 66.0° | 66.0° | 66.0° | 66.0° | 66.0° |
| F | FORK RAKE (inch) | 1.7 | 1.7 | 1.7 | 1.7 | 1.7 |
| G | TRAIL (inch) | 4.4 | 4.4 | 4.8 | 4.8 | 4.8 |
| H | WHEELBASE (inch) | 44 | 44.9 | 44.7 | 45.6 | 46.5 |
| I | CHAIN STAY LENGTH (inch) | 17.2 | 17.2 | 17.2 | 17.2 | 17.2 |
| J | BOTTOM BRACKET DROP (inch) | 2.4 | 2.4 | 2.4 | 2.4 | 2.4 |
| K | STACK (inch) | 23.9 | 24.3 | 24.3 | 24.7 | 25 |
| L | REACH (inch) | 15.5 | 16.1 | 16 | 16.7 | 17.4 |
| M | STAND OVER HEIGHT (inch) | 24.1 | 26 | 26 | 28 | 29 |
| N | HANDLEBAR WIDTH (inch) | 29.9 | 29.9 | 29.9 | 29.9 | 30.7 |
| O | STEM LENGTH (inch) | 1.6 | 1.6 | 1.6 | 2 | 2 |
| P | CRANK LENGTH (inch) | 6.5 | 6.7 | 6.7 | 6.7 | 6.7 |
| Q | WHEEL SIZE | 27.5" | 27.5" | 29" | 29" | 29" |
